Leyard TVF1.2 specs
Offering pixel pitches of 0.9, 1.2, 1.5 and 1.8 millimeters, the Leyard TVF Series is a leader in fine pitch LED video wall displays. This series is recognized for its superior visual quality and ease of installation. The stackable, cableless design simplifies setup by eliminating cabinet-to-cabinet cabling, while front serviceability ensures quick and easy maintenance.
Physical
- Pixel pitch
- 1.26 mm
- Cabinet size (W×H×D)
- 605 × 340 × 73 mm
- Weight
- 6.9 kg
- Weight per m²
- 33.7 kg/m²
- Cabinet type
- Fixed install
- Service access
- Front & rear
- Cabinet resolution
- 480 × 270 px (16:9)
- Pixel density
- 629,882 px/m²
- Brightness (calibrated)
- 600 nits
- Refresh rate
- 3,840 Hz
- Contrast
- 7,000:1
- Viewing angle (H/V)
- 160° / 140°
- LED type
- SMD
- Processing depth
- 16 bit
Power & thermal
- Max power
- 130 W
- Average power
- 43 W
- Max power per m²
- 632 W/m²
- Average power per m²
- 209 W/m²
- Thermal load
- 444 BTU/h per cabinet
Environment
- Rated for
- Indoor
- Operating temperature
- -10 to 40 °C
- LED lifetime
- 100,000 h
- Certifications
- CE, RoHS
Manufacturer details
- Marketed by
- Leyard Europe (EMEA)
- Part number
- TVF1.2
- Power supply
- Single / Redundant (optional)
- Frame rates hz
- 50, 60
- Power published
- Single PSU: 130 W/Cab (632 W/m2) / Red PSU: 159 W/Cab (773 W/m2)
- Weight published
- Single PSU: 6.94 kg (33.73 kg/m2) / Red PSU: 7.76 kg (37.72 kg/m2)
- Color temperature
- 3000-10000K
- Module dimensions
- 302.4 x 170.1mm
- Module resolution
- 240x135
- Module composition
- 2x2
- Pixel configuration
- Commercial grade 3-in-1 Black SMD
- Brightness published
- Single PSU: 600 / Red PSU: 800
All variations in the TVF series
All Leyard cabinets →Every Leyard TVF series cabinet and the exact pitch, size and brightness pairing it ships with.
- Leyard TVF0.90.945 mm605×340 mm600 nits
- TVF1.2this model1.26 mm605×340 mm600 nits
- Leyard TVF1.51.575 mm605×340 mm600 nits
- Leyard TVF1.81.89 mm605×340 mm600 nits
Controllers that drive this panel
All controllers →Each cabinet carries 129,600 px, so a controller's port budget and total capacity decide how much wall it drives. Its receiving card is not published — confirm the control ecosystem with your supplier before ordering.
- Colorlight U15 MaxColorlightConfirm ecosystem
2,000cabinets
400 × Mixed520M px total · port-bound
Wire it - NovaStar H20NovaStarConfirm ecosystem
2,000cabinets
400 × Mixed260M px total · port-bound
Wire it - NovaStar MX6000 ProNovaStarConfirm ecosystem
1,087cabinets
64 × Mixed141M px total · capacity-bound
Wire it - NovaStar H15NovaStarConfirm ecosystem
1,000cabinets
200 × Mixed130M px total · port-bound
Wire it - Colorlight U9 MaxColorlightConfirm ecosystem
500cabinets
100 × Mixed260M px total · port-bound
Wire it - Colorlight U6 MaxColorlightConfirm ecosystem
500cabinets
100 × Mixed130M px total · port-bound
Wire it
Counts assume one cabinet per port-chain hop at 60 Hz / 8-bit. Open Leyard TVF1.2 in the calculator to lay out the real chains and validate them.
Design a wall with this panelFrequently asked
- How much power does the Leyard TVF1.2 draw?
- Each Leyard TVF1.2 cabinet draws up to 130 W at full white and about 43 W with typical content — 632 W/m² max. A 10-cabinet wall therefore needs up to 1,300 W plus headroom.
- What is the resolution of the Leyard TVF1.2?
- One cabinet is 480 × 270 pixels at a 1.26 mm pixel pitch (629,882 px/m²). About 8 cabinets side by side reach 4K width (≈ 4.84 m).
- How heavy is a Leyard TVF1.2 wall?
- A single cabinet weighs 6.9 kg (33.7 kg/m²). A 5 × 3 wall of 15 cabinets weighs about 104 kg before mounting structure.
- Is the Leyard TVF1.2 suitable for outdoor use?
- No — the Leyard TVF1.2 is an indoor cabinet. Its 600 nits suit controlled lighting, not direct sun.
