ROE Visual CB5MKII RGBW specs

ROE Visual offers two advanced full-spectrum LED panels designed for studio production. Based on the Carbon Series CB5 panel, these so-caled RGB+ panels are available in a Carbon CB5 MKII RGBW and Carbon CB5 MKII RGBCA version. These panels provide superior color rendering accuracy, optimized for on-camera use, ensuring true-to-life visuals in demanding environments like broadcasting and filmmaking.

Pitch
5.76923 mm
Size
600×1200 mm
Nits
4,400 nits3,200 nits
Open in calculatorCompareControllersRunning cost
ROE Visual CB5MKII RGBW LED cabinet

Physical

Pixel pitch
5.76923 mm
Cabinet size (W×H×D)
600 × 1,200 × 80 mm
Weight
17.5 kg
Weight per m²
24.3 kg/m²
Cabinet type
Rental & staging
Service access
Front & rear


Cabinet resolution
104 × 208 px (1:2)
Pixel density
30,044 px/m²
Brightness (calibrated)
3,200 nits
Refresh rate
7,680 Hz
Viewing angle (H/V)
160° / 160°
Processing depth
16 bit

Power & thermal

Max power
750 W
Average power
375 W
Max power per m²
1,042 W/m²
Average power per m²
521 W/m²
Thermal load
2,559 BTU/h per cabinet

Environment

Rated for
Indoor
IP rating (front)
IP40
IP rating (rear)
IP40
Operating temperature
-20 to 45 °C
Certifications
CE, ETL, FCC, UKCA

Manufacturer details

Ssi
68 on 3200K | 52 on 6500K
Usage
full-spectrum (RGB+W / RGB+CA) film lighting panel
Tm30 rf
80
Scan rate
1/4
Curve range
Concave 15° ~ Convex 10°
Brochure url
https://www.roevisual.com/uploads/files/Product%20File/Carbon%20Full%20Spectrum/roe-full-spectrum-brochure-sep.-30-2024.pdf
Storage temp
-40°C ~ 60°C, 10% ~ 90% RH
Btu published
2560 / 1180
Pitch published
5.77mm
Power published
750W / 375W
Weight published
17.5kg / 38.58lbs
Operating humidity
10% ~ 90% RH
Pixel configuration
RGB+White
Brightness published
3200nits
Dimensions published
600mm x 1200mm x 80mm 23.6” x 47.2” x 3.1”
Service access published
Front / Rear

All variations in the Carbon Full Spectrum series

All ROE Visual cabinets →

Every ROE Visual Carbon Full Spectrum series cabinet and the exact pitch, size and brightness pairing it ships with.

Controllers that drive this panel

All controllers →

Each cabinet carries 21,632 px, so a controller's port budget and total capacity decide how much wall it drives. Its receiving card is not published — confirm the control ecosystem with your supplier before ordering.

Counts assume one cabinet per port-chain hop at 60 Hz / 8-bit. Open ROE Visual CB5MKII RGBW in the calculator to lay out the real chains and validate them.

Design a wall with this panel

Frequently asked

How much power does the ROE Visual CB5MKII RGBW draw?
Each ROE Visual CB5MKII RGBW cabinet draws up to 750 W at full white and about 375 W with typical content — 1,042 W/m² max. A 10-cabinet wall therefore needs up to 7,500 W plus headroom.
What is the resolution of the ROE Visual CB5MKII RGBW?
One cabinet is 104 × 208 pixels at a 5.76923 mm pixel pitch (30,044 px/m²). About 37 cabinets side by side reach 4K width (≈ 22.20 m).
How heavy is a ROE Visual CB5MKII RGBW wall?
A single cabinet weighs 17.5 kg (24.3 kg/m²). A 5 × 3 wall of 15 cabinets weighs about 263 kg before mounting structure.
Is the ROE Visual CB5MKII RGBW suitable for outdoor use?
No — the ROE Visual CB5MKII RGBW is an indoor cabinet (IP40 front). Its 3,200 nits suit controlled lighting, not direct sun.
