Planar VPI2.5 specs
New Planar Venue Pro Series indoor LED video wall displays support quick setup and disassembly for corporate events, tradeshows and beyond. The next-generation solution introduces new 1.5 and 2.9 millimeter pixel pitch models to round out the lineup's existing 1.9 and 2.5 millimeter models.
Physical
- Pixel pitch
- 2.5 mm
- Cabinet size (W×H×D)
- 500 × 500 × 63 mm
- Weight
- 8 kg
- Weight per m²
- 32 kg/m²
- Cabinet type
- Rental & staging
- Service access
- Front & rear
- Cabinet resolution
- 200 × 200 px (1:1)
- Pixel density
- 160,000 px/m²
- Brightness (calibrated)
- 1,000 nits
- Refresh rate
- 3,840 Hz
- Contrast
- 5,000:1
- Viewing angle (H/V)
- 160° / 160°
Power & thermal
- Max power
- 145 W
- Average power
- 48 W
- Max power per m²
- 580 W/m²
- Average power per m²
- 192 W/m²
- Thermal load
- 495 BTU/h per cabinet
Environment
- Rated for
- Indoor
- IP rating (front)
- IP30
- IP rating (rear)
- IP30
- Operating temperature
- -20 to 40 °C
- LED lifetime
- 100,000 h
Manufacturer details
- Marketed by
- Leyard Europe (EMEA)
- Storage temp
- -40 to 60 C
- Frame rates hz
- 50/60
- Pitch published
- 2.5mm
- Color temperature
- 3000-10000 adjustable
- Module dimensions
- 250x250x14 mm
- Module resolution
- 100x100
- Module composition
- 2x2
- Operating humidity
- 10-80% RH
- Brightness uniformity
- >=97%
All variations in the Venue Pro series
All Planar cabinets →Every Planar Venue Pro series cabinet and the exact pitch, size and brightness pairing it ships with.
- Planar VPI1.51.5625 mm500×500 mm800 nits
- Planar VPI1.91.9531 mm500×500 mm1,000 nits
- VPI2.5this model2.5 mm500×500 mm1,000 nits
- Planar VPI2.92.9762 mm500×500 mm1,000 nits
- Planar VPI3.93.9062 mm500×500 mm1,000 nits
Controllers that drive this panel
All controllers →Each cabinet carries 40,000 px, so a controller's port budget and total capacity decide how much wall it drives. Its receiving card is not published — confirm the control ecosystem with your supplier before ordering.
- Colorlight U15 MaxColorlightConfirm ecosystem
6,400cabinets
400 × Mixed520M px total · port-bound
Wire it - NovaStar H20NovaStarConfirm ecosystem
6,400cabinets
400 × Mixed260M px total · port-bound
Wire it - NovaStar MX6000 ProNovaStarConfirm ecosystem
3,525cabinets
64 × Mixed141M px total · capacity-bound
Wire it - NovaStar H15NovaStarConfirm ecosystem
3,200cabinets
200 × Mixed130M px total · port-bound
Wire it - Colorlight U9 MaxColorlightConfirm ecosystem
1,600cabinets
100 × Mixed260M px total · port-bound
Wire it - Colorlight U6 MaxColorlightConfirm ecosystem
1,600cabinets
100 × Mixed130M px total · port-bound
Wire it
Counts assume one cabinet per port-chain hop at 60 Hz / 8-bit. Open Planar VPI2.5 in the calculator to lay out the real chains and validate them.
Design a wall with this panelFrequently asked
- How much power does the Planar VPI2.5 draw?
- Each Planar VPI2.5 cabinet draws up to 145 W at full white and about 48 W with typical content — 580 W/m² max. A 10-cabinet wall therefore needs up to 1,450 W plus headroom.
- What is the resolution of the Planar VPI2.5?
- One cabinet is 200 × 200 pixels at a 2.5 mm pixel pitch (160,000 px/m²). About 19 cabinets side by side reach 4K width (≈ 9.50 m).
- How heavy is a Planar VPI2.5 wall?
- A single cabinet weighs 8 kg (32 kg/m²). A 5 × 3 wall of 15 cabinets weighs about 120 kg before mounting structure.
- Is the Planar VPI2.5 suitable for outdoor use?
- No — the Planar VPI2.5 is an indoor cabinet (IP30 front). Its 1,000 nits suit controlled lighting, not direct sun.
