Planar LPO2.9 specs
High-brightness outdoor solution designed for weather, sunlight and easy setup Planar Luminate Pro Series outdoor high-brightness LED video wall displays are designed to meet the fast-paced demands of temporary event applications and fixed installations. They offer easy front or rear service access to the electronics for versatility in use, and cabinets with a quick-lock system support one-person handling.
Physical
- Pixel pitch
- 2.97619 mm
- Cabinet size (W×H×D)
- 500 × 500 × 63 mm
- Weight
- 8 kg
- Weight per m²
- 32 kg/m²
- Cabinet type
- Rental & staging
- Service access
- Front & rear
- Cabinet resolution
- 168 × 168 px (1:1)
- Pixel density
- 112,896 px/m²
- Brightness (calibrated)
- 4,500 nits
- Refresh rate
- 3,840 Hz
- Contrast
- 5,000:1
- Viewing angle (H/V)
- 160° / 160°
Power & thermal
- Max power
- 135 W
- Average power
- 54 W
- Max power per m²
- 540 W/m²
- Average power per m²
- 215 W/m²
- Thermal load
- 461 BTU/h per cabinet
Environment
- Rated for
- Outdoor
- IP rating (front)
- IP65
- IP rating (rear)
- IP65
- Operating temperature
- -30 to 50 °C
- LED lifetime
- 100,000 h
Manufacturer details
- Marketed by
- Leyard Europe (EMEA)
- Power supply
- Single
- Storage temp
- -40 to 60 C
- Frame rates hz
- 50/60
- Pitch published
- 2.97
- Weight published
- <= 8kg
- Color temperature
- 3000-10000 adjustable
- Module dimensions
- 250x250x14
- Module resolution
- 84x84
- Module composition
- 2x2
- Operating humidity
- 10-80% RH non-condensing
All variations in the Luminate Pro series
All Planar cabinets →Every Planar Luminate Pro series cabinet and the exact pitch, size and brightness pairing it ships with.
- Planar LPO2.52.5 mm500×500 mm4,000 nits
- LPO2.9this model2.97619 mm500×500 mm4,500 nits
- Planar LPO3.93.90625 mm500×500 mm4,500 nits
- Planar LPO4.84.80769 mm500×500 mm4,500 nits
Controllers that drive this panel
All controllers →Each cabinet carries 28,224 px, so a controller's port budget and total capacity decide how much wall it drives. Its receiving card is not published — confirm the control ecosystem with your supplier before ordering.
- Colorlight U15 MaxColorlightConfirm ecosystem
9,200cabinets
400 × Mixed520M px total · port-bound
Wire it - NovaStar H20NovaStarConfirm ecosystem
9,200cabinets
400 × Mixed260M px total · port-bound
Wire it - NovaStar MX6000 ProNovaStarConfirm ecosystem
4,995cabinets
64 × Mixed141M px total · capacity-bound
Wire it - NovaStar H15NovaStarConfirm ecosystem
4,600cabinets
200 × Mixed130M px total · port-bound
Wire it - Colorlight U9 MaxColorlightConfirm ecosystem
2,300cabinets
100 × Mixed260M px total · port-bound
Wire it - Colorlight U6 MaxColorlightConfirm ecosystem
2,300cabinets
100 × Mixed130M px total · port-bound
Wire it
Counts assume one cabinet per port-chain hop at 60 Hz / 8-bit. Open Planar LPO2.9 in the calculator to lay out the real chains and validate them.
Design a wall with this panelFrequently asked
- How much power does the Planar LPO2.9 draw?
- Each Planar LPO2.9 cabinet draws up to 135 W at full white and about 54 W with typical content — 540 W/m² max. A 10-cabinet wall therefore needs up to 1,350 W plus headroom.
- What is the resolution of the Planar LPO2.9?
- One cabinet is 168 × 168 pixels at a 2.97619 mm pixel pitch (112,896 px/m²). About 23 cabinets side by side reach 4K width (≈ 11.50 m).
- How heavy is a Planar LPO2.9 wall?
- A single cabinet weighs 8 kg (32 kg/m²). A 5 × 3 wall of 15 cabinets weighs about 120 kg before mounting structure.
- Is the Planar LPO2.9 suitable for outdoor use?
- Yes — it is rated for outdoor use with IP65 front ingress protection and 4,500 nits of calibrated brightness.
