Absen KLCOB1.8 V2 vs Leyard VHC-1.8
On measurable specs the Absen KLCOB1.8 V2 leads 8–3. The Leyard VHC-1.8 can still be the right call where its individual wins — check the highlighted rows — match your constraints.
| Add a panel | ||
|---|---|---|
| Physical | ||
| Pixel pitch | 1.88 mm | 1.875 mm |
| Cabinet size (W×H×D) | 600 × 338 × 39 mm | 600 × 338 × 72 mm |
| Weight per cabinet | 4.5 kg | 6.5 kg |
| Weight per m² | 22.2 kg/m² | 32.1 kg/m² |
| Image | ||
| Cabinet resolution | 320 × 180 px | 320 × 180 px |
| Pixel density | 284,024 px/m² | 284,444 px/m² |
| Brightness | 600 nits | 600 nits |
| Refresh rate | 3,840 Hz | 3,840 Hz |
| Contrast | 15,000:1 | 5,000:1 |
| Viewing angle (H/V) | 160° / 160° | 160° / 150° |
| LED type | COB | SMD |
| Processing depth | 19 bit | 14 bit |
| Power & thermal | ||
| Average power | 20 W | 42 W |
| Max power | 59 W | 103 W |
| Max power per m² | 291 W/m² | 510 W/m² |
| Thermal load per cabinet | 201 BTU/h | 352 BTU/h |
| Operational | ||
| Environment | Indoor | Indoor |
| IP rating (front) | IP40 | — |
| IP rating (rear) | IP21 | — |
| Operating temperature | 10 to 40 °C | -20 to 40 °C |
| Service access | Front | Front |
| LED lifetime | 100,000 h | 100,000 h |
| Certifications | CCC, CE, ETL, FCC, UKCA | CE, FCC, cTUVus, CB, KC, CCC, EMC Class A, EN 13501-1 |
Size a wall with either panel
The calculator shows dimensions, power, weight and a validated wiring diagram for both — swap cabinets with one click.
